Robust Highbay fixture designed for ease of installation in industrial and retail applications. In aluminium alloy EN46100 with polyester powder paint coat in black, features a polycarbonate diffuser with Protection rating IP65 and Impact resistance of IK08. Mounted via a quick connection for pendant installation. Symmetrical extra wide beam optics with a luminaire efficiency upto 135 lm/W.
| Part numbers | Luminaire power | Output flux | Output efficiency | Optics | Diffuser type | Control system/dimming | Color temperature | Emergency function |
|---|---|---|---|---|---|---|---|---|
| BVHA9840SB | 100W | 13500lm | 135lm/W | Symmetric wide | UV stabilized polycarbonate | Standard on-off | 4000K | N/A |
| BVHB9840SB | 150W | 20300lm | 135lm/W | Symmetric wide | UV stabilized polycarbonate | Standard on-off | 4000K | N/A |
| BVHA9840SC | 100W | 13500lm | 135lm/W | Symmetric wide | UV stabilized polycarbonate | Standard on-off | 4000K | N/A |
| BVHB9840SC | 150W | 20250lm | 135lm/W | Symmetric wide | UV stabilized polycarbonate | Standard on-off | 4000K | N/A |
| Part numbers | Luminaire power | Output flux | Output efficiency | Optics | Diffuser type | Control system/dimming | Color temperature | Emergency function |
|---|---|---|---|---|---|---|---|---|
| BVHC1840SB | 190W | 25600lm | 135lm/W | Symmetric wide | UV stabilized polycarbonate | Standard on-off | 4000K | N/A |
